784097-01 | TwinRX USRP Daughterboard (10 MHz - 6 GHz, 80 MHz BW, 2 RX)
The TwinRX daughterboard for the USRP™ X Series software-defined radios is a dual-channel superheterodyne receiver that offers wide dynamic range and accurate phase synchronization with LO sharing for spectrum monitoring and direction-finding applications.
783774-01 | UBX 40 USRP Daughterboard (10 MHz - 6 GHz, 40 MHz BW)
The UBX 40 daughterboard is a full-duplex wideband transceiver that covers frequencies from 10 MHz to 6 GHz with 40 MHz of instantaneous bandwidth. Coherent and phase-aligned operation across multiple UBX daughterboards on USRP X Series motherboards enables users to explore MIMO and direction finding applications. The UBX 40 daughterboard works interchangeably with other USRP daughterboards and is compatible with the USRP X Series and N Series devices.
783775-01 | UBX 160 USRP Daughterboard (10 MHz - 6 GHz, 160 MHz BW)
The UBX 160 daughterboard is a full-duplex wideband transceiver that covers frequencies from 10 MHz to 6 GHz with up to 160 MHz* of instantaneous bandwidth. Coherent and phase-aligned operation across multiple UBX daughterboards enables users to explore MIMO and direction finding applications. The UBX 160 daughterboard works interchangeably with other USRP daughterboards and is compatible with the USRP X Series devices. * The UBX 160 transmitter path has 160 MHz of bandwidth throughout the full frequency range of the device; the receiver path has 84 MHz of bandwidth for center frequencies from 10 MHz to 500 MHz.
782752-01 | LFRX USRP Daughterboard (DC - 30 MHz)
The LFRX utilizes high-speed operational amplifier to provide receive coverage from DC to 30 MHz. The LFRX is ideal for users who intend to directly receive signals in the HF band using an external LNA, or use an external front end for down conversion.
782753-01 | LFTX USRP Daughterboard (DC - 30 MHz)
The LFTX utilizes high-speed operational amplifiers to provide clean operation of the USRP from DC to 30 MHz. The LFTX is ideal for direct operation in the HF band, or for users intending to use an external front end to up-convert to higher frequencies.
782750-01 | BasicRX USRP Daughterboard (1 - 250 MHz)
The BasicRX provides a simple, wideband interface to ADC of a USRP. The BasicRX is an ideal daughterboard for users who need an external RF front end, or to inject raw signals into the USRP. A wideband transformer allows operation from 1 to 250 MHz on each channel.
782751-01 | BasicTX USRP Daughterboard (1 - 250 MHz)
The BasicTX daughterboard provides a simple, wideband interface to the DAC output(s) of a USRP. The BasicTX is an ideal daughterboard for users who want to use an external RF front end, or experiment with the raw signals provided by the USRP. A wideband transformer allows operation from 1 to 250 MHz on each channel.
